• Rear axle, 3.73 ratio
• Alternator, 160 amps (Standard on 1/2 ton models. Included and only available with (VYU) Snow Plow Prep Package on 4x4 3/4 ton models. Not available on 2WD 3/4 ton models.)
• Recovery hooks, front, frame-mounted (Not available on 2WD 1/2 ton models, except when (Z71) Off-Road Suspension Package is ordered. Included and only available with (Z71) Off-Road Suspension Package.)
• Transfer case, electronic Autotrac with rotary controls (Not available on 2WD models.)
• 4-wheel drive
• Battery, heavy-duty 600 cold-cranking amps, maintenance-free with rundown protection and retained accessory power
• Trailering equipment, heavy-duty, includes trailering hitch platform, 7-wire harness with independent fused trailering circuits mated to a 7-way sealed connector and (VR4) 2" trailering receiver
• GVWR, 7400 lbs. (3357 kg) (Requires 4x4 1/2 ton models.)
• Suspension, front coil-over-shock with stabilizer bar (1/2 ton models only.)
• Suspension, rear multi-link with coil springs (1/2 ton models only.)
• Steering, power

• Wheels, 4 - 17" x 7.5" (43.2 cm x 19.1 cm) aluminum, 5-spoke with smooth surface and rectangular pockets (1/2 ton models only. Not available with (Z71) Off-Road Suspension Package.)
• Tires, P265/70R17 all-season, blackwall (Requires 1/2 ton models. Not available with (Z71) Off-Road Suspension Package.)
• Fog lamps, front, halogen
• Tire, spare P265/70R17 (1/2 ton models only. Upgradeable to SEO (4JP) P265/70R17 on-/off road, blackwall spare tire.)
• Wheel, 17" (43.2 cm) full-size, steel spare (1/2 ton models only.)
• Tire carrier, lockable outside spare, winch-type mounted under frame at rear
• Luggage rack side rails, roof-mounted, Black
• Fascia, front color-keyed
• Fascia, rear color-keyed
• Moldings, color-keyed bodyside
• Assist steps, Black (Not available with (Z71) Off-Road Suspension Package.)
• Headlamps, dual halogen composite with automatic exterior lamp control and flash-to-pass feature
• Daytime Running Lamps, with automatic exterior lamp control
• Mirrors, outside heated power-adjustable, power-folding and driver-side auto-dimming, with integrated turn signal indicators, ground illumination and curb-tilt (Mirror caps are color-keyed. Mirror caps are satin chrome with (Z71) Off-Road Suspension Package.)
• Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield and driver- and front passenger-side glass)
• Wiper, rear intermittent with washer
• Door handles, color-keyed (Included and only available with (Z71) Off-Road Suspension Package.)
• Body, liftgate with liftglass, rear door system with rear-window wiper/washer

• Audio system, AM/FM stereo with MP3 compatible 6-disc in-dash CD changer seek-and-scan, digital clock and auto-tone control and auxiliary audio input jack (Not available with (PCJ) Sun, Entertainment and Destinations Package.)
• Audio system feature, Bose premium 9-speaker system with subwoofer in center console
• Audio system controls, rear with 2 headphone jacks (headphones not included), power outlet and controls for volume, station selection and media
• XM Satellite Radio, With a wide variety of programming, XM has something to excite any driver. Whether you want to be entertained or informed, to laugh, think, or sing, XM has the perfect channel for you - coast-to-coast, and in digital-quality sound. 3 trial months - no obligation (Available in the 48 contiguous United States. Required $12.95 monthly subscription sold separately after 3 trial months. All fees and programming subject to change. Subscription subject to customer agreement. For more information, visit gm.xmradio.com.)

• Seats, front bucket with leather-appointed seating, 10-way power driver and front passenger seat adjusters, including power lumbar control, heated seat cushion and seatbacks, 2-position driver memory, adjustable head restraints, storage pockets and floor console
• Seats, third row 50/50 split-bench 2-passenger, removable, all-belts-to-seat includes 2 cup holders and storage bin
• Console, floor with storage area, cup holders and integrated second row audio controls
• Pedals, power-adjustable for accelerator and brake
• Rear Parking Assist, Ultrasonic with rearview LED display and audible warning
• Remote vehicle starter system includes Remote Keyless Entry
• Floor covering, color-keyed carpeting
• Floor mats, color-keyed carpeted first and second row, removable
• Air conditioning, tri-zone automatic climate control with individual climate settings for driver and right-front passenger
• Universal Home Remote includes garage door opener, programmable (Deleted when (VYU) Snow Plow Prep Package is ordered.)
• Seats, second row 60/40 split-folding bench 3-passenger with center armrest
• Steering wheel, leather-wrapped
• Steering wheel controls, mounted audio and cruise controls
• Warning tones, headlamp on, key-in-ignition, driver and right-front passenger safety belt unfasten and turn signal on
• Tire Pressure Monitoring System (does not apply to spare tire)
• Windows, power with driver Express-Down and lockout features
• Door locks, power programmable with lockout protection
• Cruise control, electronic with set and resume speed
• Theft-deterrent system, vehicle, PASS-Key III
• Heater, rear auxiliary with rear passenger heating ducts
• Air conditioning, rear auxiliary
• Defogger, rear-window electric
• Power outlets, 5 auxiliary, 12-volt, includes 2 on the instrument panel, 1 in the cargo area, 1 inside the center console and 1 at the back of the console.)
• Mirror, inside rearview auto-dimming with 8-point compass and outside temperature display
• Headliner, cloth
• Visors, driver and front passenger illuminated vanity mirrors, padded with cloth trim, extends on rod
• Assist handles, front passenger and second row outboard
• Lighting, interior with dome light, driver- and passenger-side door switch with delayed entry feature, cargo lights, door handle or Remote Keyless Entry-activated illuminated entry and map lights in front and second seat positions

• StabiliTrak, stability control system with Proactive Roll Avoidance
• Brakes, 4-wheel antilock, 4-wheel disc, VAC power (1/2 ton models only.)
• OnStar, 1-year of Directions and Connections plan. Includes the innovative easy to use Turn-by-Turn Navigation services which provide voice-guided directions (where available). Also includes Automatic Notification of Air Bag Deployment, Stolen Vehicle Location Assistance, Emergency Services, Roadside Assistance, Remote Door Unlock, OnStar Vehicle Diagnostics, Hands-Free Calling, AccidentAssist, Remote Horn and Lights, Information and Convenience Services, and Driving Directions (OnStar services require vehicle electrical system (including battery), wireless service and GPS satellite signals to be available and operating for features to function properly. OnStar acts as a link to existing emergency service providers. Stolen Vehicle Location Assistance and Remote Door Unlock success varies with conditions. OnStar Vehicle Diagnostics available on most 2004 MY and newer GM vehicles. Diagnostic capability varies by model. Turn-by-Turn Navigation requires ABS and is not available in certain areas. Visit onstar.com or call 1-888-466-7827 for system limitations and details.)
• Air bags, dual-stage frontal, driver and right-front passenger with Passenger Sensing System (right-front passenger air bag status on overhead console) (Always use safety belts and the correct child restraints for your childs age and size. Even in vehicles equipped with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
• Air bags, head curtain side-impact, first and second row outboard seating positions with rollover sensor, includes third row seating positions with (AS3) 3-passenger third row 50/50 split-bench seat or (AW2) 2-passenger third row 50/50 split-bench seat (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your childs age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
• Safety belts, 3-point, driver and front passenger in all seating positions
• LATCH system (Lower Anchors and Top tethers for CHildren), for child safety seats

CONVENIENCE PACKAGE 2

• includes (E61) rear power-operated liftgate
• (XA7) heated windshield washer fluid system and (CE1) Rainsense front intermittent wipers

TRANSMISSION, 4-SPEED AUTOMATIC, ELECTRONICALLY CONTROLLED

• with overdrive and tow/haul mode (STD)

SKID PLATE PACKAGE

• includes front underbody shield starting behind front bumper and running to first cross-member
• protecting front underbody
• oil pan
• differential case and transfer case
• frame-mounted shields

SEATS, THIRD ROW 50/50 SPLIT-BENCH

• 3-passenger
• removable
• all-belts-to-seat

LT PREFERRED EQUIPMENT GROUP

• Includes Standard Equipment

SUNROOF, POWER, TILT-SLIDING

• with express-open and close and wind deflector

SUN, ENTERTAINMENT AND DESTINATIONS PACKAGE

• includes (UVB) AM/FM stereo with MP3 compatible CD/DVD player and DVD-based navigation
• (U42) rear seat entertainment system
• (UVC) rearview camera system and (CF5) power sunroof.

AUDIO SYSTEM WITH NAVIGATION, AM/FM STEREO WITH MP3 COMPATIBLE CD/DVD PLAYER AND DVD-BASED NAVIGATION

• seek-and-scan
• digital clock
• auto-tone control
• Radio Data System (RDS)
• speed-compensated volume
• TheftLock
• auxiliary audio input jack and voice recognition
• plays CD or DVD in upper slot

SUSPENSION PACKAGE, OFF-ROAD

• Includes off-road jounce bumpers
• specially-tuned springs and gas-charged monotube shocks
• (G80) heavy-duty locking rear differential
• (B71) front and rear wheel flares
• (N87) 4-18" x 8" (45.7 cm x 20.3 cm) aluminum wheels
• (QXN) P265/65R18 on-/off-road
• blackwall tires
• (NZZ) Skid Plate Package
• (BVV) tubular assist steps and (BPH) Z71 Off-Road Appearance Package which consists of unique front fascia
• satin chrome door handles
• grille insert and mirror caps. Also includes (V76) front frame-mounted recovery hooks.

ENGINE, VORTEC 5.3L V8 SFI FLEXFUEL WITH ACTIVE FUEL MANAGEMENT

• capable of running on unleaded or up to 85% ethanol (310 hp [231.1 kW] @ 5200 rpm
• 335 lb-ft of torque [452.3 N-m] @ 4400 rpm)
• aluminum block (STD)

REAR AXLE, 3.73 RATIO

• (STD)

SEATS, SECOND ROW BUCKET

• with leather-appointed seating
• reclining

ENTERTAINMENT SYSTEM, REAR SEAT DVD PLAYER

• with remote control
• overhead display
• 2 sets of 2-channel wireless infrared headphones and auxiliary audio/video input jacks

SEATS, FRONT BUCKET

• with leather-appointed seating
• 10-way power driver and front passenger seat adjusters
• including power lumbar control
• heated seat cushion and seatbacks
• 2-position driver memory
• adjustable head restraints
• storage pockets and floor console (STD)

• AIR CLEANER HIGH-CAPACITY
• DIFFERENTIAL HEAVY-DUTY LOCKING REAR
• CONVENIENCE PACKAGE 2 includes (E61) rear power-operated liftgate (XA7) heated windshield washer fluid system and (CE1) Rainsense front intermittent wipers
• TIRES P265/65R18 ON-/OFF-ROAD BLACKWALL
• TRANSMISSION 4-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED with overdrive and tow/haul mode (STD)
• SKID PLATE PACKAGE includes front underbody shield starting behind front bumper and running to first cross-member protecting front underbody oil pan differential case and transfer case frame-mounted shields
• SEAT RELEASE SECOND ROW POWER RELEASE ONLY
• SEATS THIRD ROW 50/50 SPLIT-BENCH 3-passenger removable all-belts-to-seat
• REARVIEW CAMERA SYSTEM
• LT PREFERRED EQUIPMENT GROUP Includes Standard Equipment
• WHEELS 4 - 18 X 8 (45.7 CM X 20.3 CM) ALUMINUM
• LUGGAGE RACK CENTER RAILS
• LIGHT TITANIUM/EBONY CUSTOM LEATHER-APPOINTED SEAT TRIM
• SUNROOF POWER TILT-SLIDING with express-open and close and wind deflector
• BLUE GRANITE METALLIC
• SUN ENTERTAINMENT AND DESTINATIONS PACKAGE includes (UVB) AM/FM stereo with MP3 compatible CD/DVD player and DVD-based navigation (U42) rear seat entertainment system (UVC) rearview camera system and (CF5) power sunroof.
• SEATS HEATED SECOND ROW
• AUDIO SYSTEM WITH NAVIGATION AM/FM STEREO WITH MP3 COMPATIBLE CD/DVD PLAYER AND DVD-BASED NAVIGATION seek-and-scan digital clock auto-tone control Radio Data System (RDS) speed-compensated volume TheftLock auxiliary audio input jack and voice recognition plays CD or DVD in upper slot
• SUSPENSION PACKAGE OFF-ROAD Includes off-road jounce bumpers specially-tuned springs and gas-charged monotube shocks (G80) heavy-duty locking rear differential (B71) front and rear wheel flares (N87) 4-18 x 8 (45.7 cm x 20.3 cm) aluminum wheels (QXN) P265/65R18 on-/off-road blackwall tires (NZZ) Skid Plate Package (BVV) tubular assist steps and (BPH) Z71 Off-Road Appearance Package which consists of unique front fascia satin chrome door handles grille insert and mirror caps. Also includes (V76) front frame-mounted recovery hooks.
• ENGINE VORTEC 5.3L V8 SFI FLEXFUEL WITH ACTIVE FUEL MANAGEMENT capable of running on unleaded or up to 85% ethanol (310 hp [231.1 kW] @ 5200 rpm 335 lb-ft of torque [452.3 N-m] @ 4400 rpm) aluminum block (STD)
• REAR AXLE 3.73 RATIO (STD)
• SEATS SECOND ROW BUCKET with leather-appointed seating reclining
• ENTERTAINMENT SYSTEM REAR SEAT DVD PLAYER with remote control overhead display 2 sets of 2-channel wireless infrared headphones and auxiliary audio/video input jacks
• SEATS FRONT BUCKET with leather-appointed seating 10-way power driver and front passenger seat adjusters including power lumbar control heated seat cushion and seatbacks 2-position driver memory adjustable head restraints storage pockets and floor console (STD)
• Tow Hooks
• Four Wheel Drive
• Tow Hitch
• Power Steering
• Aluminum Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Fog Lamps
• Conventional Spare Tire
• Luggage Rack
• Running Boards/Side Steps
• Automatic Headlights
• Daytime Running Lights
• Automatic Headlights
• Heated Mirrors
• Power Mirror(s)
• Integrated Turn Signal Mirrors
• Power Folding Mirrors
• Privacy Glass
• Intermittent Wipers
• AM/FM Stereo
• CD Changer
• CD Player
• MP3 Capability
• Auxiliary Audio Input
• Premium Sound System
• Rear Seat Audio Controls
• Power Outlet
• Satellite Radio
• Requires Subscription
• Power Driver Seat
• Power Passenger Seat
• Leather Seats
• Bucket Seats
• Heated Front Seat(s)
• Driver Adjustable Lumbar
• Passenger Adjustable Lumbar
• Seat Memory
• 3rd Row Seat
• Pass-Through Rear Seat
• Rear Seat Audio Controls
• Adjustable Pedals
• Rear Parking Aid
• Keyless Entry
• Power Door Locks
• Remote Engine Start
• Floor Mats
• Climate Control
• Multi-Zone A/C
• A/C
• Rear A/C
• Universal Garage Door Opener
• Pass-Through Rear Seat
• Rear Bench Seat
• Adjustable Steering Wheel
• Leather Steering Wheel
• Cruise Control
• Steering Wheel Audio Controls
• Tire Pressure Monitor
• Power Windows
• Power Door Locks
• Cruise Control
• Immobilizer
• A/C
• Rear A/C
• Rear Defrost
• Power Outlet
• Auto-Dimming Rearview Mirror
• Driver Vanity Mirror
• Passenger Vanity Mirror
• Driver Illuminated Vanity Mirror
• Passenger Illuminated Visor Mirror
• Front Reading Lamps
• Rear Reading Lamps
• Traction Control
• Stability Control
• ABS
• 4-Wheel Disc Brakes
• Telematics
• Navigation from Telematics
• Requires Subscription
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag Sensor
• Front Head Air Bag
• Rear Head Air Bag

• Vehicle
• Rear Door Type: Liftgate
• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 19
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 160
• Cooling System
• Total Cooling System Capacity (qts): 18.3
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 4200
• Curb Weight - Front (lbs): 2923
• Curb Weight - Rear (lbs): 2672
• Gross Vehicle Weight Rating Cap (lbs): 7400
• Gross Combined Wt Rating (lbs): 13,000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1050
• Suspension
• Suspension Type - Front: Coil springs
• Suspension Type - Rear: Coil springs
• Spring Capacity - Front (lbs): 3600
• Spring Capacity - Rear (lbs): 4200
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-floating
• Axle Capacity - Front (lbs): 3925
• Axle Capacity - Rear (lbs): 4200
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 1.81
• Shock Absorber Diameter - Rear (mm): 1.81
• Stabilizer Bar Diameter - Front (in): 1.41
• Stabilizer Bar Diameter - Rear (in): 1.10
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.0 x 1.18
• Rear Brake Rotor Diam x Thickness (in): 13.5 x 0.79
• Tires
• Front Tire Order Code: QXN
• Front Tire Order Code: QAN
• Rear Tire Order Code: QXN
• Rear Tire Order Code: QAN
• Spare Tire Order Code: ZVL
• Front Tire Size: P265/65R18
• Front Tire Size: P265/70R17
• Rear Tire Size: P265/65R18
• Rear Tire Size: P265/70R17
• Spare Tire Size: P265/70R17
• Front Tire Capacity (lbs): 2104
• Rear Tire Capacity (lbs): 2104
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 18 x 8
• Front Wheel Size (in): 17 x 7.5
• Rear Wheel Size (in): 18 x 8
• Rear Wheel Size (in): 17 x 7.5
• Spare Wheel Size (in): 17 x - TBD -
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 17.75
• Steering Ratio (:1), At Lock: 17.75
• Turning Diameter - Curb to Curb (ft): 43.0
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 31
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 130.0
• Length, Overall w/rear bumper (in): 222.4
• Width, Max w/o mirrors (in): 79.1
• Height, Overall (in): 76.8
• Overhang, Front (in): - TBD -
• Overhang, Rear w/bumper (in): - TBD -
• Ground to Top of Load Floor (in): 32.6
• Ground Clearance, Front (in): 10.5
• Ground Clearance, Rear (in): 9.1
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): 101.8
• Cargo Area Length @ Floor to Seat 2 (in): 69.6
• Cargo Area Length @ Floor to Seat 3 (in): 35.6
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 49.1
• Cargo Box (Area) Height (in): 41.4
• Cargo Volume to Seat 1 (ft³): 137.4
• Cargo Volume to Seat 2 (ft³): 90.0
• Cargo Volume to Seat 3 (ft³): 45.8
• Interior Dimensions
• Passenger Capacity: 7
• Front Head Room (in): 41.1
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.3
• Front Hip Room (in): 64.4
• Second Head Room (in): 38.5
• Second Leg Room (in): 39.5
• Second Shoulder Room (in): 65.2
• Second Hip Room (in): 61.8
• Third Head Room (in): 38.1
• Third Leg Room (in): 34.9
• Third Shoulder Room (in): 64.7
• Third Hip Room (in): 49.4
• Summary
• Vehicle Name: Chevrolet Suburban
• Body Style: 4 Door 1500
• Body Code: E52
